Danfoss VLT AutomationDrive FC 300 Programming Manual page 169

Parameter Lists
1-10 Motor Construction
1-01 Motor Control Principle
1-80 Function at Stop
1-81 Min Speed for Function at
Stop [RPM]
(Par. 002 = rpm)
1-82 Min Speed for Function at
4 4
Stop [Hz]
(Par. 002 = Hz)
1-83 Precise Stop Function
1-84 Precise Stop Counter Value
1-85 Precise Stop Speed Compen-
sation Delay
1-90 Motor Thermal Protection
1-91 Motor External Fan
1-93 Thermistor Resource
1-95 KTY Sensor Type
1-96 KTY Thermistor Resource
1-97 KTY Threshold level
2-00 DC Hold Current
2-01 DC Brake Current
2-02 DC Braking Time
2-03 DC Brake Cut In Speed [RPM]
2-04 DC Brake Cut In Speed [Hz]
2-05 Maximum Reference
2-10 Brake Function
2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-13 Brake Power Monitoring
2-15 Brake Check
2-16 AC brake Max. Current
2-17 Over-voltage Control
2-18 Brake Check Condition
2-19 Over-voltage Gain
2-20 Release Brake Current
2-21 Activate Brake Speed [RPM]
2-22 Activate Brake Speed [Hz]
2-23 Activate Brake Delay
2-24 Stop Delay
2-25 Brake Release Time
2-26 Torque Ref
2-27 Torque Ramp Time
2-28 Gain Boost Factor
9) Not AC brake
168
FC 300 Programming Guide
AC motor
Flux open
U/f mode VVC+
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+
+
see 9)
+ +
+ +
+ +
+
+
see 9)
- +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
- -
- -
- -
- -
- -
®
