Parameter Descriptions
Bit 0 Digital Output Terminal 27
Bit 1 Digital Output Terminal 29
Bit 2 Digital Output Terminal X 30/6
Bit 3 Digital Output Terminal X 30/7
Bit 4 Relay 1 output terminal
Bit 5 Relay 2 output terminal
Bit 6 Option B Relay 1 output terminal
Bit 7 Option B Relay 2 output terminal
Bit 8 Option B Relay 3 output terminal
Bit 9-15 Reserved for future terminals
Bit 16 Option C Relay 1 output terminal
Bit 17 Option C Relay 2 output terminal
Bit 18 Option C Relay 3 output terminal
Bit 19 Option C Relay 4 output terminal
Bit 20 Option C Relay 5 output terminal
Bit 21 Option C Relay 6 output terminal
Bit 22 Option C Relay 7 output terminal
Bit 23 Option C Relay 8 output terminal
Bit 24-31 Reserved for future terminals
5-93 Pulse Out #27 Bus Control
Range: Function:
0.00 % [0.00 - 100.00 Set the output frequency transferred to
*
%] the output terminal 27 when the
terminal is configured as 'Bus
Controlled' in 5-60 Terminal 27 Pulse
Output Variable [45].
5-94 Pulse Out #27 Timeout Preset
Range: Function:
0.00 % [0.00 - 100.00 Set the output frequency transferred to
*
%] the output terminal 27 when the terminal
is configured as 'Bus Ctrl Timeout' in
5-60 Terminal 27 Pulse Output Variable
[48]. And a time-out is detected.
5-95 Pulse Out #29 Bus Control
Range: Function:
0.00 % [0.00 - 100.00 Set the output frequency transferred to
*
%] the output terminal 29 when the terminal
is configured as 'Bus Controlled' in
5-63 Terminal 29 Pulse Output Variable
[45].
This parameter only applies for FC 302.
5-96 Pulse Out #29 Timeout Preset
Range: Function:
0.00 % [0.00 - Set the output frequency transferred to
*
100.00 %] the output terminal 29 when the terminal
is configured as 'Bus Ctrl Timeout' in
5-63 Terminal 29 Pulse Output Variable [48].
And a time-out is detected.
This parameter only applies for FC 302.
FC 300 Programming Guide
5-97 Pulse Out #X30/6 Bus Control
Range:
0.00 %
5-98 Pulse Out #X30/6 Timeout Preset
Range:
0.00 %
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
Function:
[0.00 - 100.00 Set the output frequency transferred to
*
%] the output terminal X30/6 when the
terminal is configured as 'Bus Controlled'
in 5-66 Terminal X30/6 Pulse Output
Variable, Terminal X30/6 Pulse Output
Variable [45].
Function:
[0.00 - 100.00 Set the output frequency transferred to
*
%] the output terminal X30/6 when the
terminal is configured as 'Bus Ctrl
Timeout' in 5-66 Terminal X30/6 Pulse
Output Variable [48]. And a time-out is
detected.
