Parameter Descriptions
[55] DigiPot INCREASE signal to the Digital Potentiometer
Increase function described in parameter group 3-9*
[56] DigiPot DECREASE signal to the Digital Potentiometer
Decrease function described in parameter group 3-9*
[57] DigiPot Clear Clears the Digital Potentiometer reference
described in parameter group 3-9*
[60] Counter A (Terminal 29 or 33 only) Input for increment
counting in the SLC counter.
[61] Counter A (Terminal 29 or 33 only) Input for decrement
counting in the SLC counter.
[62] Reset Input for reset of counter A.
Counter A
[63] Counter B (Terminal 29 or 33 only) Input for increment
counting in the SLC counter.
[64] Counter B (Terminal 29 or 33 only) Input for decrement
counting in the SLC counter.
[65] Reset Input for reset of counter B.
Counter B
[70] Mech. Brake Brake feedback for hoisting applications: Set
Feedback 1-01 Motor Control Principle to [3] flux w/ motor
feedback; set 1-72 Start Function to [6] Hoist
mech brake Ref.
[71] Mech. Brake Inverted brake feedback for hoisting
Feedback inv. applications
[72] PID error When enabled, it inverts the resulting error
inverse from the process PID controller. Available only
if "Configuration Mode" is set to "Surface
Winder", "Extended PID Speed OL" or
"Extended PID Speed CL".
[73] PID reset I- When enabled, resets the I-part of the Process
part PID controller. Equivalent to 7-40 Process PID
I-part Reset. Available only if "Configuration
Mode" is set to "Surface Winder", "Extended
PID Speed OL" or "Extended PID Speed CL".
[74] PID enable When enabled, enables the extended process
PID controller. Equivalent to 7-50 Process PID
Extended PID. Available only if "Configuration
Mode" is set "Extended PID Speed OL" or
"Extended PID Speed CL".
[80] PTC Card 1 All Digital Inputs can be set to PTC Card 1 [80].
However, only one Digital Input must be set to
this choice.
[91] Profidrive The functionality is the same as the according
OFF2 control word bit of the Profibus/Profinet
option.
[92] Profidrive The functionality is the same as the according
OFF3 control word bit of the Profibus/Profinet
option.
[98] Start edge Edge triggered start command. Keeps the start
triggered command alive, even if the input is going back
to low - can be used for a start push-button.
5-10 Terminal 18 Digital Input
Option: Function:
[8] Start Functions are described under 5-1* Digital Inputs
*
FC 300 Programming Guide
5-11 Terminal 19 Digital Input
Option:
[10]
5-12 Terminal 27 Digital Input
Option:
[2]
5-13 Terminal 29 Digital Input
Option:
[14]
5-14 Terminal 32 Digital Input
Option:
[0]
5-15 Terminal 33 Digital Input
Option:
[0]
5-16 Terminal X30/2 Digital Input
Option:
[0]
5-17 Terminal X30/3 Digital Input
Option:
[0]
5-18 Terminal X30/4 Digital Input
Option:
[0]
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
Function:
Reversing Functions are described under 5-1* Digital Inputs
*
Function:
Coast inverse Functions are described under 5-1* Digital
*
Inputs
Function:
Select the function from the available digital input
range and the additional options [60], [61], [63] and
[64]. Counters are used in Smart Logic Control
functions.This parameter is available for FC 302 only.
Jog Functions are described under 5-1* Digital Inputs
*
Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in Smart
Logic Control functions.
No operation Functions are described under 5-1* Digital
*
Inputs
Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in Smart
Logic Control functions.
No operation Functions are described under 5-1* Digital
*
Inputs
Function:
No operation This parameter is active when option module
*
MCB101 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
Function:
No operation This parameter is active when option module
*
MCB101 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
Function:
No operation This parameter is active when option module
*
MCB101 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
