Danfoss VLT AutomationDrive FC 300 Programming Manual page 78

Parameter Descriptions
[120] Local reference Output is high when 3-13 Reference Site =
active [2] Local or when 3-13 Reference Site = [0]
Linked to hand auto at the same time as the
LCP is in [Hand on] mode.
Reference site set
in 3-13 Reference
Site
Reference site:
Local
3-13 Reference Site
[2]
Reference site:
Remote
3-13 Reference Site
[1]
Reference site:
Linked to Hand/
Auto
Hand
Hand -> off
Auto -> off
Auto
[121] Remote Output is high when 3-13 Reference Site =
reference active Remote [1] or Linked to hand/auto [0] while
the LCP is in [Auto on] mode. See above.
[122] No alarm Output is high when no alarm is present.
[123] Start command Output is high when there is an active Start
active command (i.e. via digital input bus
connection or [Hand on] or [Auto on]), and
no Stop or Start command is active.
[124] Running Output is high when the frequency
reverse converter is running counter clockwise (the
logical product of the status bits 'running'
AND 'reverse').
[125] Drive in hand Output is high when the frequency
mode converter is in [Hand on] mode (as
indicated by the LED light above [Hand
on]).
[126] Drive in auto Output is high when the frequency
mode converter is in [Hand on] mode (as
indicated by the LED light above [Auto
on]).
[151] ATEX ETR cur. Selectable if 1-90 Motor Thermal Protection
alarm is set to [20] or [21]. If the alarm 164 ATEX
ETR cur.lim.alarm is active, the output will
be 1.
[152] ATEX ETR freq. Selectable if 1-90 Motor Thermal Protection
alarm is set to [20] or [21]. If the alarm 166 ATEX
ETR freq.lim.alarm is active, the output will
be 1.
[153] ATEX ETR cur. Selectable if1-90 Motor Thermal Protection
warning is set to [20] or [21] ]. If the alarm 163 ATEX
FC 300 Programming Guide
[154] ATEX ETR freq.
Local Remote
referenc reference
[189] External fan
e active
active [121]
[120]
1 0
5-30 Terminal 27 Digital Output
Option:
[0]
0 1
5-31 Terminal 29 Digital Output
Option:
[0]
1 0
5-32 Term X30/6 Digi Out (MCB 101)
1 0
Option:
0 0
0 1
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
ETR cur.lim.warning is active, the output
will be 1.
Selectable if 1-90 Motor Thermal Protection
warning is set to [20] or [21]. If the warning 165
ATEX ETR freq.lim.warning is active, the
output will be 1.
The internal logics for the internal fan
control control is transferred to this output to
make it possible to control an external fan
(relevant for HP duct cooling).
Function:
No operation Functions are described under 5-3* Digital
*
Outputs
Function:
No operation Functions are described under 5-3* Digital
*
Outputs
This parameter only applies to FC 302
Function:
No operation This parameter is active when
*
option module MCB 101 is
mounted in the frequency
converter. Functions are described
under 5-3* Digital Outputs
Control ready
Drive ready
Drive rdy/rem ctrl
Enable / no warning
Running
Running / no warning
Run in range/no warn
Run on ref/no warn
Alarm
Alarm or warning
At torque limit
Out of current range
Below current, low
Above current, high
Out of speed range
Below speed, low
Above speed, high
Out of feedb. range
Below feedback, low
Above feedback, high
Thermal warning
Ready,no thermal W
Remote,ready,no TW
Ready, Voltage OK
Reverse
Bus OK
3 3
77
