Parameter Descriptions
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB 113),
Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6] (MCB 105),
Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option: Function:
Bus Control. In the event of bus time-
out the output state is set high (On).
[47] Bus ctrl, 0 if timeout Controls output via bus. The state of
the output is set in 5-90 Digital & Relay
Bus Control. In the event of bus time-
out the output state is set low (Off).
[51] MCO controlled Active when a MCO 302 or MCO 305 is
connected. The output is controlled
from option.
[60] Comparator 0 See parameter group 13-1* (Smart
Logic Control). If Comparator 0 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[61] Comparator 1 See parameter group 13-1* (Smart
Logic Control). If Comparator 1 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[62] Comparator 2 See parameter group 13-1* (Smart
Logic Control). If Comparator 2 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[63] Comparator 3 See parameter group 13-1* (Smart
Logic Control). If Comparator 3 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[64] Comparator 4 See parameter group 13-1* (Smart
Logic Control). If Comparator 4 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[65] Comparator 5 See parameter group 13-1* (Smart
Logic Control). If Comparator 5 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[70] Logic rule 0 See parameter group 13-4*(Smart
Logic Control). If Logic Rule 0 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
[71] Logic rule 1 See parameter group 13-4*(Smart
Logic Control). If Logic Rule 1 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
[72] Logic rule 2 See parameter group 13-4*(Smart
Logic Control). If Logic Rule 2 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
FC 300 Programming Guide
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB 113),
Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6] (MCB 105),
Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[73]
[74]
[75]
[80]
[81]
[82]
[83]
[84]
[85]
[120] Local ref active
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
Function:
Logic rule 3 See parameter group 13-4*(Smart
Logic Control). If Logic Rule 3 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 4 See parameter group 13-4*(Smart
Logic Control). If Logic Rule 4 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 5 See parameter group 13-4*(Smart
Logic Control). If Logic Rule 5 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
SL digital output A See 13-52 SL Controller Action. Output
A is low on Smart Logic Action [32].
Output A is high on Smart Logic
Action [38].
SL digital output B See 13-52 SL Controller Action. Output
B is low on Smart Logic Action [33].
Output B is high on Smart Logic
Action [39].
SL digital output C See 13-52 SL Controller Action. Output
C is low on Smart Logic Action [34].
Output C is high on Smart Logic
Action [40].
SL digital output D See 13-52 SL Controller Action. Output
D is low on Smart Logic Action [35].
Output D is high on Smart Logic
Action [41]
SL digital output E See 13-52 SL Controller Action. Output
E is low on Smart Logic Action [36].
Output E is high on Smart Logic
Action [42].
SL digital output F See 13-52 SL Controller Action. Output
F is low on Smart Logic Action [37].
Output F is high on Smart Logic
Action [43].
Output is high when 3-13 Reference
Site = [2] Local or when 3-13 Reference
Site = [0] Linked to hand auto at the
same time as the LCP is in [Hand on]
mode.
