Parameter Descriptions
10-12 Process Data Config Read
Select the process read data for I/O Assembly Instances 101/151.
Elements [2] and [3] of this array can be selected. Elements [0] and
[1] of the array are fixed.
Option:
[3424] PCD 4 Read from MCO
[3425] PCD 5 Read from MCO
[3426] PCD 6 Read from MCO
[3427] PCD 7 Read from MCO
[3428] PCD 8 Read from MCO
[3429] PCD 9 Read from MCO
[3430] PCD 10 Read from MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded Position
[3452] Actual Master Position
[3453] Slave Index Position
[3454] Master Index Position
[3455] Curve Position
[3456] Track Error
[3457] Synchronizing Error
[3458] Actual Velocity
[3459] Actual Master Velocity
[3460] Synchronizing Status
[3461] Axis Status
[3462] Program Status
[3464] MCO 302 Status
[3465] MCO 302 Control
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
FC 300 Programming Guide
0
Function:
[0]
[1]
[0]
[1]
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
10-13 Warning Parameter
Range: Function:
[0 - View a DeviceNet-specific Warning word. One bit is
*
65535 ] assigned to every warning. Please refer to the
DeviceNet Operating Instructions (MG.33.DX.YY) for
further information.
Bit: Meaning:
0 BusNetwork not active
1 Explicit connection timeout
2 I/O connection
3 Retry limit reached
4 Actual is not updated
5 CAN bus off
6 I/O send error
7 Initialization error
8 No bus supply
9 Bus off
10 Error passive
11 Error warning
12 Duplicate MAC ID Error
13 RX queue overrun
14 TX queue overrun
15 CAN overrun
10-14 Net Reference
Read only from LCP
Option: Function:
Select the reference source in Instance 21/71 and 20/70.
Off Enables reference via analog/digital inputs.
*
On Enables reference via the fieldbus.
10-15 Net Control
Read only from LCP
Option: Function:
Select the control source in Instance 21/71 and 20/70.
Off Enables control via analog/digital inputs.
*
On Enable control via the fieldbus.
