Introduction
Input polarity of control terminals
PNP (Source)
Digital input wiring
12 13 18 19 27 29
NPN (Sink)
Digital input wiring
12 13 18 19 27 29
NOTE
Control cables must be screened/armoured.
See section entitled Earthing of Screened/Armoured Control
Cables for the correct termination of control cables.
FC 300 Programming Guide
32 33 20 37
32 33 20 37
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
1.1.6 Start/Stop
Terminal 18 = 5-10 Terminal 18 Digital Input [8] Start
Terminal 27 = 5-12 Terminal 27 Digital Input [0] No operation
(Default coast inverse)
Terminal 37 = Safe stop (where available)
12 13 18 19
Start/Stop
Speed
Start/Stop
[18]
27 29 32 33 20 37
Safe Stop
9
1 1
