Parameter Descriptions
1-91 Motor External Fan
Option: Function:
[0] No No external fan is required, i.e. the motor is derated at
*
low speed.
[1] Yes Applies an external motor fan (external ventilation), so
no derating of the motor is required at low speed. The
upper curve in graph above (fout = 1 x fM,N) is followed
if the motor current is lower than nominal motor current
(see 1-24 Motor Current). If the motor current exceeds
nominal current, the operation time still decreases as if
no fan were installed.
1-93 Thermistor Source
Option: Function:
Select the input to which the thermistor
(PTC sensor) should be connected. An
analog input option [1] or [2] cannot be
selected if the analog input is already in
use as a reference source (selected in
3-15 Reference 1 Source, 3-16 Reference 2
Source or 3-17 Reference 3 Source).
When using MCB 112, choice [0] None must
always be selected.
[0] None
*
[1] Analog input 53
[2] Analog input 54
[3] Digital input 18
[4] Digital input 19
[5] Digital input 32
[6] Digital input 33
NOTE
This parameter cannot be adjusted while the motor is
running.
NOTE
Digital input should be set to [0] PNP - Active at 24V in
5-00 Digital I/O Mode.
1-94 ATEX ETR cur.lim. speed reduction
FC 302 only.
Only visible if 1-90 Motor Thermal Protection is set to [20] or [21].
Range:
0.0 % [0.0 - 100.0 %]
*
The reaction for operating in Ex-e current limit must be
configured.
0%: The drive does not change anything besides issuing
warning 163 ATEX ETR cur.lim.warning.
>0%: The drive issuing warning 163 and reduces motor
speed following ramp 2 (parameter group 3-5*).
FC 300 Programming Guide
Example:
Actual reference = 50 RPM
1-94 ATEX ETR cur.lim. speed reduction = 20%
Resulting reference = 40 RPM
1-95 KTY Sensor Type
Option:
[0]
[1]
[2]
1-96 KTY Thermistor Resource
Option:
[0]
[2]
1-97 KTY Threshold level
Range:
80 C
1-98 ATEX ETR interpol. points freq.
FC 302 only.
Only visible if 1-90 Motor Thermal Protection is set to [20] or [21].
Range:
Application
dependent
Function:
Enter the four frequency points [Hz] from the motor name
plate into this array. Together with 1-99 ATEX ETR interpol
points current, these make up a table (f [Hz],I [%]).
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
Function:
Select the used type of KTY sensor. FC 302
only.
KTY Sensor 1 1 kΩ at 100 o
C
*
KTY Sensor 2 1 kΩ at 25 o
C
KTY Sensor 3 2 kΩ at 25
o C
Function:
Selecting analog input terminal 54 to be used
as KTY sensor input. Terminal 54 cannot be
selected as KTY source if otherwise used as
reference (see 3-15 Reference Resource 1 to
3-17 Reference Resource 3).
FC 302 only.
NOTE
Connection of KTY-sensor between term.
54 and 55 (GND). See picture in section
KTY Sensor Connection.
None
*
Analog
input 54
Function:
[-40 - 140 C] Select the KTY sensor threshold level for
*
motor thermal protection.
FC 302 only.
[Application
dependant]
*
3
Function:
Definition of thermal
limitation curve.
