Parameter Descriptions
3.10 Parameters: 8-** Communications and
Options
3.10.1 8-0* General Settings
3
3
8-01 Control Site
Option:
[0]
Digital and
*
ctrl.word
[1]
Digital only
[2]
Controlword only
8-02 Control Word Source
Select the source of the control word: one of two serial interfaces or
four installed options. During initial power-up, the frequency
converter automatically sets this parameter to Option A [3] if it
detects a valid fieldbus option installed in slot A. If the option is
removed, the frequency converter detects a change in the config-
uration, sets 8-02 Control Word Source back to default setting
RS-485, and the frequency converterr then trips. If an option is
installed after initial power-up, the setting of 8-02 Control Word
Source will not change but the frequency converter will trip and
display: Alarm 67 Option Changed.
When you retrofit a bus option into a drive, that did not have a bus
option installed to begin with, you must take an ACTIVE decision to
move the control to Bus based. This is done for safety reasons in
order to avoid an accidental change.
This parameter cannot be adjusted while the motor is running.
Option:
[0]
[1]
[2]
[3]
*
[4]
[5]
[6]
[30]
8-03 Control Word Timeout Time
Range:
1.0 s
[Application
*
dependant]
102
FC 300 Programming Guide
Function:
The setting in this parameter overrides
the settings in 8-50 Coasting Select to
8-56 Preset Reference Select.
Control by using both digital input and
control word.
Control by using digital inputs only.
Control by using control word only.
Function:
None
FC RS485
FC USB
Option A
Option B
Option C0
Option C1
External Can
Function:
Enter the maximum time expected to pass
between the reception of two consecutive
telegrams. If this time is exceeded, it
indicates that the serial communication
has stopped. The function selected in
8-04 Control Word Timeout Function will
then be carried out. The time-out counter
is triggered by a valid control word.
MG.33.MB.02 - VLT
8-04 Control Word Timeout Function
Select the time-out function. The time-out function activates when
the control word fails to be updated within the time period
specified in 8-03 Control Word Timeout Time.
Option:
[0]
Off
Resumes control via serial bus (Fieldbus or
*
standard) using the most recent control
word.
[1]
Freeze output Freezes output frequency until communi-
cation resumes.
[2]
Stop
Stops with auto restart when communication
resumes.
[3]
Jogging
Runs the motor at JOG frequency until
communication resumes.
[4]
Max. speed
Runs the motor at maximum frequency until
communication resumes.
[5]
Stop and trip
Stops the motor, then resets the frequency
converter in order to restart: via the fieldbus,
via the reset button on the LCP or via a digital
input.
[7]
Select setup 1 Changes the set-up upon reestablishment of
communication following a control word
time-out. If communication resumes causing
the time-out situation to disappear, 8-05 End-
of-Timeout Function defines whether to
resume the set-up used before the time-out
or to retain the set-up endorsed by the time-
out function.
[8]
Select setup 2 See [7] Select setup 1
[9]
Select setup 3 See [7] Select setup 1
[10] Select setup 4 See [7] Select setup 1
[26] Trip
NOTE
The following configuration is required in order to change
the set-up after a time-out:
Set 0-10 Active Set-up to [9] Multi set-up and select the
relevant link in 0-12 This Set-up Linked to.
8-05 End-of-Timeout Function
Option:
Function:
Select the action after receiving a valid control
word following a time-out. This parameter is
active only when 8-04 Control Timeout Function
is set to [Set-up 1-4].
[0]
Hold set-up Retains the set-up selected in 8-04 Control
Timeout Function and displays a warning, until
8-06 Reset Control Timeout toggles. Then the
frequency converter resumes its original set-up.
[1]
Resume set-
Resumes the set-up active prior to the time-
*
up
out.
®
is a registered Danfoss trademark
