Description: Displays the time in milliseconds referred to the day that the alarm was resolved.
Dependency: See also: r2122, r2123, r2124, r2134, r2145, r2146
NOTICE
The time comprises r2146 (days) and r2125 (milliseconds).
Note
The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
The structure of the alarm buffer and the assignment of the indices is shown in r2122.
r2130[0...63]

Fault received in days

Data type: Unsigned16
Description: Displays the time in days referred to the day that the fault occurred.
Dependency: See also: r0945, r0947, r0948, r0949, r2109, r2133, r2136
NOTICE
The time comprises r2130 (days) and r0948 (milliseconds).
Note
The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
r2131

Actual fault number

Data type: Unsigned16
Description: Displays the number of the active fault that occurred last.
Note
0: No fault present.
r2132

Actual alarm value

Data type: Unsigned16
Description: Displays the alarm that last occurred.
Note
0: No alarm present.
r2133[0...63]

Fault value for float values

Data type: FloatingPoint32
Description: Displays the additional information about the fault that occurred for float values.
Refer to the fault for the interpretation of the fault value.
Dependency: See also: r0945, r0947, r0948, r0949, r2109, r2130, r2136
Note
The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
r2134[0...63] Alarm value for float values
Data type: FloatingPoint32
Description: Displays the additional information about the alarm that occurred for float values.
Refer to the alarm for an interpretation of the alarm value.
Dependency: See also: r2122, r2123, r2124, r2125, r2145, r2146
Note
The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
SINAMICS S210 servo drive system
Operating Instructions, 12/2017, A5E41702836B AA
P group: Messages
P group: Messages
P group: Messages
P group: Messages
P group: Messages
Parameters
12.2 List of parameters
