  • Page 1 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120...

  • Page 3: Instructions For The

    Introduction Fundamental safety instructions for the SIMOTICS documentation SIMOTICS Description of the motors Drive technology Mounting and options SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Preparing for use Operating Instructions Mounting Connecting Commissioning Operation Faults and their rectification Maintenance Decommissioning and...

  • Page 4: Commissioning

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 5: Introduction

    About these operating instructions These operating instructions apply to the SIMOTICS S-1FK2 servo motor, referred to as "1FK2" in this document. The Operating Instructions provide information about the components that enable the target group to install, set up, test, commission, operate, and troubleshoot the products and systems correctly and safely.
  • Page 6 ● Using documentation online (find and search in manuals / information) More information (https://support.industry.siemens.com/cs/ww/en/view/108998034) If you have any questions regarding the technical documentation (e.g. suggestions, corrections), please send an e-mail to the following address: E-mail (mailto:docu.motioncontrol@siemens.com) SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 7 Products (http://www.siemens.com/motioncontrol) Websites of third parties This publication contains hyperlinks to websites of third parties. Siemens does not take any responsibility for the contents of these websites or adopt any of these websites or their contents as their own, because Siemens does not control the information on these websites and is also not responsible for the contents and information provided there.

  • Page 9: Table Of Contents

    Cooling ............................ 36 Holding brake .......................... 36 Preparing for use ..........................39 Shipping and packaging ......................39 Transportation and storage ..................... 40 4.2.1 Transport ..........................40 4.2.2 Storage ........................... 43 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 10 Service and inspection intervals .................... 81 10.2.2 Cleaning ..........................82 10.2.3 Motor replacement on reaching the bearing life ..............83 10.3 Repair ............................. 83 10.3.1 How to replace a 1FK2 motor ....................83 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 11 Technical data and characteristics ......................87 Dimension drawings ..........................89 13.1 Dimension drawing 1FK2x03 and 1FK2x04 ................89 13.2 Dimension drawing 1FK2x05 ... 1FK2x10 ................91 Glossary ............................... 93 Index..............................95 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 13: Fundamental Safety Instructions For The Simotics Documentation

    • Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV- (Protective Extra Low Voltage) output voltages for all connections and terminals of the electronics modules. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 14 • Tighten all power connections to the prescribed torque. • Check all power connections at regular intervals, particularly after equipment has been transported. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 15 • If you come closer than around 2 m to such components, switch off any radios or mobile phones. • Use the "SIEMENS Industry Online Support app" only on equipment that has already been switched off. WARNING Unrecognized dangers due to missing or illegible warning labels Dangers might not be recognized if warning labels are missing or illegible.
  • Page 16 This can also result in increased failures and reduced service lives of motors. • Comply with the specified cooling requirements for the motor. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 17: Equipment Damage Due To Electric Fields Or Electrostatic Discharge

    – Wearing ESD shoes or ESD grounding straps in ESD areas with conductive flooring • Only place electronic components, modules or devices on conductive surfaces (table with ESD surface, conductive ESD foam, ESD packaging, ESD transport container). SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 18: Industrial Security

    In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Products and solutions from Siemens constitute one element of such a concept.

  • Page 19: Residual Risks Of Power Drive Systems

    6. Influence of network-connected communication systems, e.g. ripple-control transmitters or data communication via the network For more information about the residual risks of the drive system components, see the relevant sections in the technical user documentation. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 21: Description Of The Motors

    If you wish to use special versions and design variants whose specifications vary from the motors described in this document, then contact your local Siemens office. If you have any questions regarding the intended usage, please contact your local Siemens office.

  • Page 22: Technical Features And Environmental Conditions

    Installed and operated with a converter, the motor - together with the Power Drive System - must comply with the requirements laid down in the applicable EMC Directive. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 23 Quality systems Siemens AG employs a quality management system that meets the requirements of ISO 9001 and ISO 14001. Certificates for SIMOTICS motors can be downloaded from the Internet at the following link: Certificates for SIMOTICS motors (https://support.industry.siemens.com/cs/ww/de/ps/13347/cert)

  • Page 24: General Technical Features

    AM22DQC absolute encoder 22 bit + 12 bit multiturn • Holding brake Optionally installed, 24 V DC Connection Connectors for power and signals, rotatable Paint finish Anthracite, similar to RAL7016 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 25: Environmental Conditions

    • In hazardous areas with a danger of explosion You will find additional data on the environmental conditions, such as for transport and storage of the motor, in Chapter "Transportation and storage (Page 40)". SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 26: Degree Of Protection

    1FK2❑10 The motors are certified for a wide range of installation and operating conditions. These conditions such as rigid or vibration-isolated foundation design influence noise emission, sometimes significantly. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 27: Derating Factors

    Structure of the article number The article number describes the motor with the following structure. Figure 2-1 Article number structure for 1FK2 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 28 Absolute encoder, multiturn, 22 bit + 12 bit (encoder AM22DQC) Connection type 2CC (two-wire technology) for S 120 Revision number Start 1) More detailed information is provided in the associated Catalog NC 82. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 29: Rating Plate Data

    / rpm 9 Data of the holding brake 20 Certifications 10 Manufacturer's address 21 Standard for all rotating electrical ma- chines 11 Stall current 22 Data matrix code SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 31: Mounting And Options

    38 (k6) × 80 10 × 8 × 70 The shaft extension 11 mm × 23 mm can only be supplied without a keyway and without a shaft sealing ring (IP65). SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 32: Bearing Version

    All radial forces always refer to aligned forces. NOTICE Motor damage caused by circulating forces Circulating forces can cause bearing motion, and therefore damage the motor. • Circulating forces are not permissible. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 33 (L10h) of 25000 h. Radial force diagram 1FK2x03 Figure 3-2 Maximum permissible radial force at a distance x from the flange for a nominal bearing lifetime of 25000 h SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 34 25000 h Radial force diagram 1FK2105 Figure 3-4 Maximum permissible radial force at a distance x from the flange for a nominal bearing lifetime of 25000 h SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 35 25000 h Radial force diagram 1FK2x06 Figure 3-6 Maximum permissible radial force at a distance x from the flange for a nominal bearing lifetime of 25000 h SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 36 25000 h Radial force diagram 1FK2210 Figure 3-8 Maximum permissible radial force at a distance x from the flange for a nominal bearing lifetime of 25000 h SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 37: Thermal Motor Protection

    (ESDS). • Avoid touching the terminals directly with hands or tools. They may be electrostatically charged and damage components. The encoders are suitable for the Extended Safety Functions. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 38: Cooling

    The spring-loaded brake has a magnets and the brake opens torsional backlash less than 1°. without any residual torque. The permanent magnet brake has a torsionally stiff connection to the motor rotor. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 39 Subsequent conversion of motors with or without a holding brake is not possible. The technical data for the holding brake is contained in the Configuration Manual of the motor. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 41: Preparing For Use

    ● Upon receipt of the delivery, check immediately whether the items delivered match the accompanying documents. Note Siemens will not accept any claims for missing or incorrect items submitted at a later date. ● Report any visible transportation damage to the delivery company immediately.

  • Page 42: Transportation And Storage

    • Only use lifting slings that are suitable for the weight of the motor. • Attach the lifting slings as shown in the figure "Lifting and transporting with lifting slings". Figure 4-1 Lifting and transporting with lifting slings (example diagram) SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 43 • Do not use bent or damaged eyebolts. • Only use eyebolts with laminated fiber washers. • Loads applied transversely to the plane of the eyebolts are not permitted. ① Lifting eyes 1FK2 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 44 • After the motor has been set down, secure it in position. • Do not release the lifting devices until the motor has been secured in position. 4. Secure the motor against unintentional movements. ❒ SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 45: Storage

    Store the motor in a dry, dust-free, and vibration-free indoor storage facility. Adhere to the following values: ● v < 0.2 mm/s ● Max. temperatures: -15° C to 55° C ● Mean relative humidity < 75% SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 46 The following ambient conditions encourage the formation of condensation: ● Large fluctuations of the ambient temperature ● Direct sunshine ● High air humidity during storage. Avoid these ambient conditions. Use a dehydrating agent in the packaging. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 47: Mounting

    Contact with rotating parts can cause death or severe injury. • Do not touch any rotating parts. • Mount a cover cap or protective shroud over freely rotating parts. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 48 • Ensure that no temperature-sensitive parts come into contact with hot surfaces. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 49: Checklists Prior To Mounting

    Are the mounting surfaces free of corrosion? Do the mounting dimensions (e.g. shaft diameter, shaft length, true run) on the cus- tomer machine meet the specification? SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 50: Mounting Instructions

    20 Nm 1FK2❑06 8 (d2 = 15) 20 Nm 1FK2❑08 10 (d2 = 18) 35 Nm 1FK2❑10 12 (d2 = 20) 60 Nm Tightening torques for fastening bolts SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 51: Mounting The Drive Elements

    Mount or remove the power output elements (e.g. couplings, gear wheels, belt pulleys) using suitable devices only (see figure). ● Use the threaded hole in the shaft extension. ● If required, heat up the output elements before mounting or removing. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 52 Intermediate washer/disk (to protect the centering in the shaft extension) Figure 5-1 Mounting and removing output elements The motor dimensions can be found in Chapter "Dimension drawings (Page 89)" - or in the relevant catalog. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 53: Vibration Response

    The vibration acceleration is evaluated in the frequency range from 10 Hz to 2000 Hz. The maximum peak in the measurement time range is considered. The vibration values must not exceed the specified limits at any measuring location. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 54 End shield NDE radial ② ⑤ End shield DE radial End shield NDE axial ③ ⑥ End shield DE axial End shield NDE radial Figure 5-3 Measuring points for vibration values SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 55: Connecting

    • When connected to IT line supplies, a monitoring device must signal the first fault between an active part and ground. Eliminate this fault immediately. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 56: Permissible Line System Types

    ● Observe the data on the rating plate and the circuit diagrams. ● Adapt the connecting cables to the type of use and the voltages and currents that occur. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 57 Connecting 6.3 System integration ● Use prefabricated cables from SIEMENS (not in the scope of delivery). These cables reduce installation costs and increase operational reliability (see the Product Information). ● Make sure that the inside of the connector is clean and free of cable cuttings and moisture.

  • Page 58: Rotating The Connector On The Motor

    Table 6- 3 Rotation range of the power connector Motor Connector size of Angle α Angle α' Drawing the power connector ① 1FK2❑03 1FK2❑04 1FK2❑05 1FK2❑06 1FK2❑08 1FK2❑10 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 59: Power Connection

    The power connectors can be rotated within a certain range. More precise information about the equipping of the motors and the angles of rotation is provided in Chapter "Rotating the connector on the motor (Page 56)". SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 60: Signal Connection

    (Page 56)" 6.3.4 Connecting to a converter 6.3.4.1 Selecting and connecting the cables ● Use prefabricated MOTION-CONNECT cables from SIEMENS or shielded connecting cables. ● The prefabricated MOTION-CONNECT cables reduce installation costs and increase the operational reliability Note The cable shielding, made up of as many strands as possible, must have a high electrical conductivity.
  • Page 61 BD1+ and BD2- = brake cable without lettering, 1.5 mm , shielded together PE = protective conductor ⑤ Cable shield ⑥ Conductor designations ⑦ Recommended length of the cable ends: 105 mm SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 62 BD1+ and BD2- = brake cable without lettering, 1.5 mm , shielded together PE = protective conductor ⑤ Cable shield ⑥ Conductor designations ⑦ Recommended length of the cable ends: 105 mm SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 63 Recommended length of the cable ends: 105 mm Lock the round connector properly on the motor Information on locking is provided in Chapter "Handling the quick-action locking (Page 62)". SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 64: Handling The Quick-Action Locking

    You can also connect quick-connection cables with SPEED-CONNECT to motor connectors as conventional cables with screw locks (fully threaded). Note We recommend cables with SPEED-CONNECT because they are easier to use. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 65 (position B) Minimum locking Maximum locking up to the end stop Note A secure connection is only guaranteed from position A onward. You have established a secure connection. ❒ SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 66: Routing Cables In A Damp Environment

    If the motor is mounted in a humid environment, the power and signal cables must be routed as shown in the following figure. Figure 6-1 Routing cables in a damp environment SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 67: Commissioning

    • Never touch the terminals when making measurements or immediately after the measurement. • Check the connected supply feeder cables to ensure that the line supply voltage cannot be connected. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 68 Impermissible speeds can cause damage to the motor. • Ensure that the maximum permissible speed is not exceeded. Realize this using a suitable control system or activate the speed monitoring function in the drive. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 69 Operating the motor holding brake outside its permissible voltage range at the motor connection will damage the brake. • Ensure that the motor holding brake is only operated within its permissible voltage range. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 70: Checklists For Commissioning

    Has the belt drive tension been correctly adjusted? • Have the gear tooth flank and gear tooth tip play as well as radial play been cor- • rectly adjusted for geared outputs? SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 71 Table 7- 6 Checklist (6) - Checks regarding the optional brake Check Is the brake open when the operating voltage is applied? Does the brake open and close correctly? SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 72: Commissioning Procedure

    2. Follow the steps of the commissioning tool, for example, "Startdrive", to commission the motor. You have commissioned the motor. ❒ Switching off ● Switch off the motor at the frequency converter. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 73: Switching On And Switching Off

    3. Check the function of the safety equipment. 4. Check whether the motor reaches the required parameters You have switched on the motor. ❒ Switching off ● Switch off the motor at the frequency converter. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 75: Operation

    The temperature of certain parts of the motor can exceed 100 °C. Physical contact can cause serious burns. Check the temperature of the parts before touching them and take appropriate protective measures if necessary. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 76: Switching On And Switching Off

    Make sure that: ● The power consumption is in the specified range ● Cooling is ensured ● There is no abnormal motor noise ● The motor does not overheat SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 77: Stationary States

    Chapter "Commissioning (Page 65)". ● Before switching on to recommission the system, carefully observe the notes in Chapter "Switching on and switching off (Page 71)". SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 79: Faults And Their Rectification

    Humming sound in operation High temperature rise under no-load op- eration High temperature rise under load Uneven running Grinding sound, running noise Radial vibrations M N O P Axial vibrations SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 80 Fault originating from the gearbox Adjust/repair gearbox If the fault still cannot be resolved after taking the measures stated above, please contact the manufacturer or the Siemens Service Center. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 81: Maintenance

    7. Make sure that the machine is completely locked ... and that you have the right machine. After you have completed the work, restore operational readiness by performing the above steps in the reverse order. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 82 • If using chemical cleaning agents, observe the instructions and any warnings provided in the relevant safety data sheet. Chemical cleaning agents must be suitable for use with the machine's components, particularly where plastic components are concerned. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 83: Inspection And Maintenance

    ● Perform the following maintenance measures as specified in the table. Maintenance and repair of the motor can be performed by Siemens Service Centers throughout the world. Contact your personal Siemens contact if you require this service.

  • Page 84: Cleaning

    • Avoid pressurized water on connectors, terminal boxes, and other live parts. Clean the motor of dust and dirt as required. In this way, you ensure adequate heat dissipation. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 85: Motor Replacement On Reaching The Bearing Life

    If you want to replace the motor with a motor with a different article number, you must perform converter commissioning after replacing the motor. You will find more precise information in the manual for the converter in question SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 86 – Connect the motor plug. Detailed information is provided in Chapter "Notes for connecting the round connector at the motor (Page 62)". 3. Switch the converter on. You have replaced the motor. ❒ SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 87: Decommissioning And Disposal

    4. Remove the fixing elements from the motor. 5. Transport the motor to a suitable location for disposal. You have removed the motor. ❒ Dispose of the motor in accordance with the local legal requirements. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 88: Dismantling The Motor

    For environmentally-friendly recycling and disposal of your old device, please contact a company certified for the disposal of waste electrical and electronic equipment, and dispose of the old device as prescribed in the respective country of use. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 89: Technical Data And Characteristics

    Technical data and characteristics You will find the technical data for the various shaft heights of the motors in the Configuration Manual in Chapter "Technical data and characteristics". SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 91: Dimension Drawings

    IP65 diagonal f / mm e / mm b / mm f1 / f1 / a / mm f2 / mm s / mm 1FK2❑03 50(j6) 1FK2❑04 70(j6) SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 92 1FK2❑03-..-0 14(h6) x 30 21.5 1FK2❑03-..-1 1FK2❑03-..-2 11(k6) x 23 1FK2❑04 19(k6) x 40 21.5 You will find further dimensions in the dimension drawings in the relevant catalog. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 93: Dimension Drawing 1Fk2X05

    / mm b / mm f1 / mm a / mm f2 / mm s / mm 1FK2105 95(j6) 10.5 1FK2205 80(j6) 1FK2❑06 110(j6) 1FK2❑08 130(j6) 11.5 1FK2❑10 180(j6) SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
  • Page 94 19(k6) x 40 21.5 1FK2❑06 24(k6) x 50 1FK2❑08 32(k6) x 58 1FK2❑10 38(k6) x 80 You will find further dimensions in the dimension drawings in the relevant catalog. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 95: Glossary

    ≥ the rated torque M Stall current I Motor phase current to generate the particular stall torque (M • I ). Specification of the RMS value of a sinusoidal current. SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...

  • Page 97: Index

    Inspection and maintenance, 79 Lifting and transporting the motor, 40 Maintenance intervals, 81 Motor replacement Bearing damage, 83 Noise emission, 24 Radial force loading, 31 Rating plate, 27 RoHS, 21 SIMOTICS S-1FK2 synchronous motors for SINAMICS S120 Operating Instructions, 06/2019, A5E46089564B AB...
