Customizable protection
• Motor overload.
• Excess start time.
• Undercurrent/overcurrent.
• Underpower/overpower.
• Current imbalance.
• Input trip.
• Motor thermistor.
Optional features for advanced applications
• Smart cards.
• Communication options:
- DeviceNet.
- EtherNet/IP.
- Modbus RTU.
- Modbus TCP.
- PROFIBUS.
- PROFINET.

3.2 Type Code

0 4 1
MCD6-
Illustration 1: Type Code String
Danfoss A/S © 2018.10
0 – –
B T 5
– –
System Design
Control voltage
CV1 = 24 V AC/V DC
CV2 = 110~120 V AC or
220~240 V AC
Protection
00 = IP00 (open frame)
20 = IP20 (enclosed)
Frame size
S1X = Frame size 1
S2X = Frame size 2
Mains voltage
T5 = 200~525 V AC
T7 = 380~690 V AC
Bypass
B = Internally bypassed
Nominal current rating
