Ordering type code

The DMS is available in the following variants:
- Standard
- Standard with Brake
- Extended
- Extended with Brake
- Extended with Brake & Reversing

Certifications

The DMS 300 has CE, UL, cUL and C-tick
certifications. The details are as under:
CE
Rated insulation voltage ............................................................................................................................ 500 VAC
Rated impulse withstand ........................................................................................... 2.0 kV (1.2/ 50 micro second)
Conducted and radiated frequency emissions ................................................................ Class B as per EN 55011
Electrostatic discharge, 4 kV contact and 8 kV air discharge ................................................ no effect on operation
Radio frequency electromagnetic field, 0.15 MHz to 1.0 GHz ................................................ no effect on operation
Fast transients, 2.0 kV/ 5.0 kHz ............................................................................................ no effect on operation
Surges, 2.0 kV line to earth, 1.0 kV line to line ....................................................................... no effect on operation
Voltage dips and short interruptions ...................................................................................... no effect on operation
Short circuit tested on 5 kA supply, when protected by semiconductor fuses (Type 2 co-ordination) ................... no
damage to DMS 300, no danger to persons or installation
Short circuit tested on 5 kA supply, when protected by HRC fuses (Type 1 co-ordination) ................................... no
danger to persons or installation, DMS unit may be unsuitable for future use
UL
C-tick
IP66
To maintain certifications, the product shall not be
modified an any way, shall be used only for the specified
purpose, and must be installed according to this manual
and/or any other authorized Danfoss instruction.
16
DMS Manual
The Extended varaints are available with integrated
Fieldbus AS-i interface. The extended versions can be
delivered with Profibus interface including 4 additional
M12 plugs for connection of external sensors.
Refer to the table for the Part numbers
corresponding to the variants.
For example, the part number for a Motor Mount
DMS unit, with Reversing function, and without
Fieldbus connection would be:
DMS330PT4P66ERD0F00T12C0
