4 Specifications

4.1 Supply

Mains voltage (L1, L2, L3)
MCD6-xxxxB-T5
MCD6-xxxxB-T7
Control voltage (A7, A8, A9)
MCD6-xxxxB-xx-CV2 (A8, A9)
MCD6-xxxxB-xx-CV2 (A7, A9)
MCD6-xxxxB-xx-CV1 (A8, A9)
Mains frequency
Rated insulation voltage
Rated impulse withstand voltage
Form designation

4.2 Short-circuit Capability

Coordination with semiconductor fuses
Coordination with HRC fuses

4.3 Electromagnetic Capability (Compliant with EU Directive 2014/35/EU)

EMC Immunity
EMC Emmissions

4.4 Inputs

Input rating
Motor thermistor (TER-05, TER-06)

4.5 Outputs

Relay outputs
Main contactor (13, 14)
Relay output A (21, 22, 23)
Relay output B (33, 34)
Analog output (AO-07, AO-08)
Maximum load
Accuracy
Danfoss A/S © 2018.10
110–120 V AC (+10%/-15%), 600 mA
220–240 V AC (+10%/-15%), 600 mA
Bypassed or continuous, semiconductor motor starter form 1
Active 24 V DC, 8 mA approximately
10 A @ 250 V AC resistive, 5 A @ 250 V AC AC15 pf 0.3
AQ262141844215en-000202 / 175R1174 | 25
Specifications
200–525 V AC (±10%)
380–690 V AC (±10%)
24 V AC/V DC (±20%), 2.8 A
50–60 Hz (±5 Hz)
690 V AC
6 kV
Type 2
Type 1
IEC 60947-4-2
IEC 60947-4-2 Class B
Trip >3.6 kΩ, reset >1.6 kΩ
Normally open
Changeover
Normally open
600 Ω (12 V DC @ 20 mA)
±5%
