Type Code String - Danfoss VLT AQUA Design Manual

4. How to Order

4.1.2. Type Code String

Description
Product group & VLT Series
4 Power rating
Number of phases
Mains voltage
Enclosure
RFI filter
Brake
Display
Coating PCB
Mains option
Adaptation
Adaptation
Software release
Software language
A options
B options
C0 options MCO
C1 options
C option software
D options
Table 4.1: Type code description.
The various options are described further in the
76
Pos Possible choice
1-6 FC 202
8-10 0.25 - 630 kW
11 Three phases (T)
T 2: 200-240 VAC
T 4: 380-480 VAC
11-12
T 6: 525-600 VAC
T 7:
E20: IP20
E21: IP 21/NEMA Type 1
E55: IP 55/NEMA Type 12
E2M: IP21/NEMA Type 1 w/mains shield
13-15
E5M: IP 55/NEMA Type 12 w/mains shield
E66: IP66
P21: IP21/NEMA Type 1 w/backplate
P55: IP55/NEMA Type 12 w/backplate
H1: RFI filter class A1/B
H2: RFI filter class A2
16-17
H3: RFI filter class A1/B (reduced cable length)
H4: RFI filter class A2/A1
X: No brake chopper included
B: Brake chopper included
18
T: Safe Stop
U: Safe + brake
G: Graphical Local Control Panel (GLCP)
19 N: Numeric Local Control Panel (NLCP)
X: No Local Control Panel
X. No coated PCB
20
C: Coated PCB
X: No Mains disconnect switch
21
1: With Mains disconnect switch
22 Reserved
23 Reserved
24-27 Actual software
28
AX: No options
A0: MCA 101 Profibus DP V1
29-30 A4: MCA 104 DeviceNet
AG: MCA 108 Lonworks
AJ: MCA 109 BACnet gateway
BX: No option
BK: MCB 101 General purpose I/O option
31-32
BP: MCB 105 Relay option
BO:MCB 109 Analog I/O option
33-34 CX: No options
35 X: No options
36-37 XX: Standard software
DX: No option
38-39
D0: DC back-up
VLT AQUA Drive Design Guide.
®
