Operating Guide | VLT® Soft Starter MCD 600

3.5 Dimensions and Weight

A
B
READY RUN TRIP LOCAL
Exit Menu
Reset Store
C D
VLT ®
Soft Starter
1/L1 3/L2 5/L3
2/T1 4/T2 6/T3
Illustration 3: Dimensions, Frame Sizes S1 (Left) and S2 (Right)
Table 5: Dimensions and Weight
Width [mm (in)]
A
MCD6-0020B 152 (6.0)
MCD6-0034B
MCD6-0042B
MCD6-0063B
MCD6-0069B
MCD6-0086B
MCD6-0108B
MCD6-0129B
MCD6-0144B 216 (8.5)
MCD6-0171B
MCD6-0194B
MCD6-0244B
MCD6-0287B
MCD6-0323B
MCD6-0410B
MCD6-0527B
MCD6-0579B
16 | Danfoss A/S © 2018.10
E
Height [mm (in)]
B C
92 (3.6) 336 (13.2)
180 (7.1) 495 (19.5)
523 (20.6)
A
B
READY RUN TRIP LOCAL
Exit Menu
Reset Store
C D
VLT ®
Soft Starter
Depth [mm (in)]
D E
307 (12.1) 231 (9.1)
450 (17.7) 243 (9.6)
System Design
E
Weight [kg (lb)]
4.8 (10.7)
4.9 (10.9)
5.5 (12.1)
12.7 (28)
15.5 (34.2)
19 (41.9)
AQ262141844215en-000202 / 175R1174
