7 Logs

7.1 Introduction

The Logs Menu provides information on events, trips, and soft starter performance.
To access the Logs Menu on the local LCP, press [Menu] and select Logs. On the remote LCP, press [Logs].

7.2 Event Log

The Event Log stores details of the most recent trips, warnings, and operations (including starts, stops, and configuration changes).
Event 1 is the most recent and event 384 is the oldest stored event.
The Event Log can be exported to an external file for analysis away from the soft starter.
See 6.7.2 File Locations and

7.3 Counters

The counters store statistics on the soft starter operation:
• Hours run (lifetime and since counter was last reset).
• Number of starts (lifetime and since counter was last reset).
• Number of times the thermal model has been reset.

7.3.1 Viewing the Counters

Procedure
1. Open the Logs, see
7.1 Introduction.
2. Scroll to Counters and press [Menu/Store].
3. Press [▵] and [▿] to scroll through the counters.
4. Press [Menu/Store] to view details.
5. To reset a counter, press [Menu/Store] then press [▵] and [▿] to select Reset/Do Not Reset.
6. Press [Store] to confirm the action.
7. Press [Menu/Store] to close the counter and return to Logs.
