Operating Guide | VLT® Soft Starter MCD 600
Parameter group number
20-1
20-2
20-3
20-4
20-5
20-6
30
30-1
30-2
30-3
30-4
30-5
30-6
30-7
30-8
30-9
30-10
30-11
30-12
30-13
30-14
30-15
31
31A
31B
31C
31D
32
32-1
32-2
32-3
32-4
32-5
32-6
33
76 | Danfoss A/S © 2018.10
Parameter group name
Tracking Gain
Pedestal Detect
Bypass Contactor Delay
Model Rating
Screen Timeout
Motor Connection
Pump Input Configuration
Pressure Sensor Type
Pressure Units
Pressure at 4 mA
Pressure at 20 mA
Flow Sensor Type
Flow Units
Flow at 4 mA
Flow at 20 mA
Units per Minute at Max Flow
Pulses per Minute at Max Flow
Units per Pulse
Depth Sensor Type
Depth Units
Depth at 4 mA
Depth at 20 mA
Flow Protection
High Flow Trip Level
Low Flow Trip Level
Flow Start Delay
Flow Response Delay
Pressure Protection
High Pressure Trip Level
High Pressure Start Delay
High Pressure Response Delay
Low Pressure Trip Level
Low Pressure Start Delay
Low Pressure Response Delay
Pressure Control
Programmable Parameters
Default setting
50%
80%
150 ms
Model dependent
1 minute
Auto-detect
None
kPa
0
0
None
liters/second
0
0
0
0
0
None
meters
0
0
10
5
00:00:500 (mm:ss:ms)
00:00:500 (mm:ss:ms)
10
00:00:500 (mm:ss:ms)
00:00:500 (mm:ss:ms)
5
00:00:500 (mm:ss:ms)
00:00:500 (mm:ss:ms)
