Operating Feedback Screens; Performance Graph - Danfoss VLT MCD 600 Operating Manual

Operating Guide | VLT® Soft Starter MCD 600
1
Mains Frequency
2
Motor pf
3
Motor power
4 Motor Temp
1 Parameter 10-10 User Parameter 3 (default: Mains frequency)
3 Parameter 10-12 User Parameter 5 (default: Motor running
power)
Illustration 23: User-configurable Screen

8.5.3 Operating Feedback Screens

The operating feedback screens show the motor running current on the top half of the screen. To select which information is shown on
the lower half, press [▵] and [▿].
• Real-time line current on each phase.
• Last start information.
• Date and time.
1
69.0 A
2
Last start
3
350% FLC
1 Motor running current
3 Maximum start current drawn (as a percentage of motor full
load current)
Illustration 24: Operating Feedback Screens

8.5.4 Performance Graph

The performance graph provides a real-time display of operating performance. Use parameters 10-2 to 10-5 to format the graph.
The display on the main LCP shows information for motor current.
52 | Danfoss A/S © 2018.10
59.7 Hz
1.01
37.0 kW
85%
010s
4
D Temp 5%
2 Parameter 10-11 User Parameter 4 (default: Power factor)
4 Parameter 10-13 User Parameter 6 (default: Motor
temperature)
2 Start duration (seconds)
4 Calculated rise in motor temperature
