Operating Guide | VLT® Soft Starter MCD 600
• IP address.
• Gateway address.
• Subnet mask.

6.9.1 Setting a Network Address

Procedure
1. Press [Menu] and select Set-up Tools.
2. Scroll to Network Address and press [Menu/Store].
3. Scroll to the required function and press [Menu/Store].
Set IP Address
192.168.000.002
st
4. The 1
digit of the address is highlighted.
5. Press [Back] and [Menu/Store] to select which digit to alter.
6. Press [▵] [▿] to change the value.
7. Press [Menu/Store] after the last digit to save the setting.
When the action has completed, the screen briefly shows a confirmation message, then returns to the previous menu level.
The network address can also be set by using parameters 12-8 to 12-19.
To configure the soft starter for use with other communication protocols, use parameters 12-1 to 12-7.

6.10 Digital I/O State

Digital I/O State
Inputs: 0100
Outputs: 100
Illustration 14: Digital I/O Status Screen
44 | Danfoss A/S © 2018.10
N O T I C E
N O T I C E
Set-up Tools
AQ262141844215en-000202 / 175R1174
