Operating Guide | VLT® Soft Starter MCD 600
Table 215: 31-3 - Flow Start Delay
Range
*00:00:500 ms 00:00:100–
30:00:000
mm:ss:ms
Table 216: 31-4 - Flow Response Delay
Range
* 00:00:500 ms 00:00:100–30:00:000
mm:ss:ms

10.20 Parameter Group 32-** Pressure Protection

The parameters in this group are only active if a smart card is installed.
Pressure protection uses terminals B23, B24 or C33, C34, C44 on the smart card.
Table 217: 32-1 - High Pressure Trip Level
Range
*10 0–5000
Table 218: 32-2 - High Pressure Start Delay
Range
* 0.5 s 00:00:100–
30:00:000
mm:ss:ms
Table 219: 32-3 - High Pressure Response Delay
Range
* 0.5 s 00:00:100–30:00:000
mm:ss:ms
Table 220: 32-4 - Low Pressure Trip Level
Range
* 5 0–5000
114 | Danfoss A/S © 2018.10
Function
Sets a delay before a flow protection trip can occur. The delay is counted from the time a start
signal is received. The flow level is ignored until the start delay has elapsed.
Function
Sets a delay between the flow passing the high or low flow trip levels, and the soft start-
er tripping.
Function
Sets the trip point for high-pressure protection.
Function
Sets a delay before a high-pressure protection trip can occur. The delay is counted from the time a
start signal is received. The pressure is ignored until the start delay has elapsed.
Function
Sets a delay between the pressure passing the high-pressure trip level and the soft starter trip-
ping.
Function
Sets the trip point for low-pressure protection.
N O T I C E
Programmable Parameters
AQ262141844215en-000202 / 175R1174
