Operating Guide | VLT® Soft Starter MCD 600
Table 92: 5-5 - Overcurrent
Range
*400% 80–600%
Table 93: 5-6 - Overcurrent Delay
Range
* 0 s 0:00–1:00 (minutes:seconds)
Table 94: 5-7 - Undervoltage
Range
*350 100–1000 V
Table 95: 5-8 - Undervoltage Delay
Range
* 1 s 0:00–1:00 (minutes:seconds)
Table 96: 5-9 - Overvoltage
Range
*500 100–1000 V
Table 97: 5-10 - Overvoltage Delay
Range
* 1 s 0:00–1:00 (minutes:seconds)
Table 98: 5-11 - Underpower
Range
*10% 10–120%
Table 99: 5-12 - Underpower Delay
Range
*1 s 0:00–1:00 (minutes:seconds)
Danfoss A/S © 2018.10
Function
Sets the trip point for overcurrent protection as a percentage of motor full load current.
Function
Slows the soft starter's response to overcurrent, avoiding trips due to momentary overcur-
rent events.
Function
Sets the trip point for undervoltage protection. Set as required.
Voltage protection does not operate correctly until the soft starter is in Run mode.
Function
Slows the soft starter's response to undervoltage, avoiding trips due to momentary fluctua-
tions.
Function
Sets the trip point for overvoltage protection. Set as required.
Function
Slows the soft starter's response to overvoltage, avoiding trips due to momentary fluctua-
tions.
Function
Sets the trip point for underpower protection. Set as required.
Function
Slows the soft starter's response to underpower, avoiding trips due to momentary fluctua-
tions.
Programmable Parameters
N O T I C E
