Operating Guide | VLT® Soft Starter MCD 600
Table 51: 3-7 - Adaptive Start Profile-2
Option
Early Acceleration
* Constant Acceleration
Late Acceleration
Table 52: 3-8 - Kickstart Time-2
Range
* 0000 ms
Table 53: 3-9 - Kickstart Level-2
Range
*500% 100–700% FLC
Table 54: 3-10 - Jog Torque-2
Range
*50% 20–100%
Table 55: 3-11 - Stop Mode-2
Option
Coast To Stop
* TVR Soft Stop
Adaptive Control
DC Brake
Soft Brake
Table 56: 3-12 - Stop Time-2
Range
*0 s 0:00–4:00 (mi-
nutes:seconds)
Danfoss A/S © 2018.10
Function
Selects which profile the VLT® Soft Starter MCD 600 uses for an adaptive control soft start.
0–2000 ms
Function
Sets the level of the kickstart current.
Function
Sets the current limit for jog operation.
Function
Sets the time for soft stopping the motor using TVR or adaptive control. If a main contactor is installed,
the contactor must remain closed until the end of the stop time. Use the main contactor output (13,
14) to control the main contactor.
Function
Sets the kickstart duration.
A setting of 0 disables kickstart.
Function
Selects the stop mode.
Programmable Parameters
