VLT® Soft Starter MCD 600
Operating Guide
• Input trip.
• Motor thermistor.
Optional features for advanced applications
• Smart cards.
• Communication options:
- DeviceNet.
- EtherNet/IP.
- Modbus RTU.
- Modbus TCP.
- PROFIBUS.
- PROFINET.
• Ground fault protection.

3.2 Type Code

0 0 6 9
MCD6-
Illustration 1: Type Code String

3.3 Selection of Soft Starter Size

The size of the soft starter must match the motor and the application.
Select a soft starter that has a current rating at least equal to the motor's full load current rating (see motor nameplate) at the start
duty.
The soft starter's current rating determines the maximum motor size it can be used with. The soft starter's rating depends on the
number of starts per hour, the length and current level of the start, and the amount of time the soft starter is off (not passing cur-
rent) between starts.
The soft starter's current rating is only valid when used in the conditions specified in the AC53 code. The soft starter may have a
higher or lower current rating in different operating conditions.
Danfoss A/S © 2020.12
B – –
T 5 S 1 X
– –
2 0 C V 1
AQ262141844215en-000401 / 175R1174 | 13
System Design
Control voltage
CV1 = 24 V AC/V DC
CV2 = 110~120 V AC or
220~240 V AC
Protection
00 = IP00 (open frame)
20 = IP20 (enclosed)
Frame size
S1X = Frame size 1
S2X = Frame size 2
S3X = Frame size 3
Mains voltage
T5 = 200~525 V AC
T7 = 380~690 V AC
Bypass
B = Internally bypassed
C = Non-bypassed (continuous
connection)
Nominal current rating
