Operating Guide | VLT® Soft Starter MCD 600
The simulation is only available when the soft starter is in ready state.
Procedure
1. Press [Menu] and select Set-up Tools.
2. Scroll to Run Simulation and press [Menu/Store].
Run Simulation
Ready
Apply Start Signal
3. Apply a start command from the selected command source.
The soft starter simulates its prestart checks and closes the main contactor relay. The Run LED flashes.
If mains voltage is connected, an error message is shown.
4. Press [Menu/Store].
The soft starter simulates starting. The Run LED flashes.
5. Press Menu/Store.
The soft starter simulates running.
6. Apply a stop command from the selected command source.
The soft starter simulates stopping. The Run LED flashes.
7. Press [Menu/Store].
The Ready LED flashes and the main contactor relay opens.
8. Press [Menu/Store].
The soft starter activates then deactivates each programmable output.
9. Press [Menu/Store].
The soft starter returns to the Set-up Tools.

6.6 Load/Save Settings

Context:
The Load/Save Settings allows:
• Resetting the soft starter parameters to default values.
• Loading parameter settings from an internal file.
• Saving the current parameter settings to an internal file.
The internal file contains default values until a user file is saved.
