4. How to Order

4.1.2. Type Code String

Description
Product group & VLT Series
4
Power rating
Number of phases
AC line voltage
Enclosure
RFI filter
Brake
Display
Coating PCB
Line option
Adaptation
Adaptation
Software release
Software language
A options
B options
C0 options MCO
C1 options
C option software
D options
4.1: Type code description.
The various options are described further in the
78
Pos Possible choice
1-6 FC 202
8-10 0.33-125 hp [0.25-90 kW]
11 Three phases (T)
11-12 T 2: 200-240 V AC
T 4: 380-480 V AC
13-15 E20: IP 20
E21: IP 21/NEMA Type 1
E55: IP 55/NEMA Type 12
E66: IP 66
P21: IP 21/NEMA Type 1 w/backplate
P55: IP 55/NEMA Type 12 w/backplate
16-17 H1: RFI filter class A1/B
H2: Class A2
H3:RFI filter A1/B (reduced cable length)
18 X: No brake chopper included
B: Brake chopper included
T: Safe Stop
U: Safe + brake
19 G: Graphical Local Control Panel (GLCP)
N: Numeric Local Control Panel (NLCP)
X: No Local Control Panel
20 X. No coated PCB
C: Coated PCB
21 X: No line power disconnect switch
1: With line power disconnect switch (IP55 only)
22 Reserved
23 Reserved
24-27 Current software
28
29-30 AX: No options
A0: MCA 101 Profibus DP V1
A4: MCA 104 DeviceNet
AG: MCA 108 LON works
31-32 BX: No option
BK: MCB 101 General purpose I/O option
BP: MCB 105 Relay option
BY: MCO 101 Extended Cascade Control
33-34 CX: No options
35 X: No options
36-37 XX: Standard software
38-39 DX: No option
D0: DC backup
