Chapter 2: Installation
|
If you have not already done so, retract the microplate carrier and then turn off
4.
and unplug the reader.
5. Remove the
6. Replace the microplate carrier
7. Tip the reader onto its back feet. Attach the
the reader using the four screws and washers (see p. 10).
8. Wrap the plastic bag around the reader and shipping panel.
9. Locate the original
bottom corners of the box. Place the
(see p. 8 and 9).
10. Grasp the handles on the shipping panel and carefully lower the reader into the
inner shipping box.
11. Slide the foam vertical supports into place around the reader. Place the
accessories box on top.
12. Close and seal the inner box with tape.
13. Place four foam corner blocks around the inner shipping box. Close and seal
the outer box with tape.
14. Write the
the box to BioTek.
Perform these steps to prepare the
1. If you have not already done so:
•
Contact BioTek's Technical Assistance Center for an
Authorization) number and shipping address before returning equipment
for service. See page 6 for contact information.
•
Decontaminate the module according to the instructions in
•
Remove the two syringes (see step 3 on the previous page) and store them
in their original boxes.
•
Detach the dispense module outlet tubes and communication cable from the
reader. Replace the two nylon screws into the Syringe 1 and 2 tubing ports
on the rear of the reader.
Refer to the illustrations in 7: Unpack and Inspect the Dispense
Module starting on page 15 when performing these steps.
2. Remove the two
plastic canisters.
3. Remove the two
fitting covers to the fittings of the outlet tubes. Place the tubes in a plastic bag.
lamp assembly and pack it in bubble wrap (see p. 13).
shipping screw
outer shipping box
RMA number in large clear numbers on the outside of the box. Ship
dispense module
inlet tubes from the syringe valves and store them in their
outlet tubes
(see p. 12).
shipping panel
. Place four foam blocks in the four
inner shipping box
for shipment:
from the syringe valves. Attach the clear plastic
to the bottom of
inside the outer box
RMA (Return Materials
Appendix A .
