Chapter 3: Getting Started
|
Inside the Synergy HT, two Teflon tubes transport fluid from the tubing ports on
the rear of the instrument to the two injectors. As shown below, both injectors are
positioned directly above the bottom fluorescence optical probe.
Figure 24: Close-up view of the injectors inside the instrument
The tubing and injectors should be cleaned at least quarterly. See
Chapter 5, Preventive Maintenance for more information.
Syringe 2
Syringe 1
Bottom probe
