Biotek Synergy HT Operator's Manual page 202

176
Appendix C: Error Codes
|
Dispense/Read Runtime/Definition Error Test Codes (lowest two digits in returned error code)
SAMPLE START LATE
FILTERSETS OUT OF RANGE
FILTER SWITCHING OVERLAP
FILTERS NOT ADJACENT
EX FILTER PLUG POSITION
INVALID MODE
DISP READ DEF NOT SET
FEATURE NOT AVAILABLE
INVALID EX WAVE
TIP PRIME TUB VOL
capacity
NUM EVENTS
INVALID EVENT
INVALID GEOMETRY
PLATE START LATE
INVALID TIP PRIME
NUM READ EVENTS
READ START TIME
NUM SAMPLES
SAMPLING INTERVAL
NUM PLATE READS
PLATE MODE READ TIME
READ START LATE
NUM DISP EVENTS
TIP PRIME VOLUME
DISP VOLUME
DISP RATE
DISP START TIME
DISP INTERVAL
DISPENSER NOT ATTACHED
DISPENSER NOT INITIALIZED
DISPENSER NOT PRIMED
INVALID DISPENSER OPERATION
DISP START LATE
NUM SHAKE EVENTS
SHAKE START TIME
READ EVENT EXPECTED
SHAKE TIME
"0" individual sample missed its scheduled start time
"01" more than two filters selected for disp/read method
"02" filter bandpass overlap condition exists in the
intermediate switching position for
reads.
"03" ex or em filters not adjacent for multi filterset
reads
"04" filter plug(s) not positioned next to ex filter(s)
for light shutter feature
"05" invalid processing mode received
"06" dispense/read protocol parameters not set or not
valid
"07" disp/read feature not enabled by dip switch
"08" excitation wavelengths must be the same for TR assay
"09" total tip prime vols in assay larger than tub
"0B" total number of events defined invalid
"C" invalid event type received
"0D" wells spaced too close for dispense operation
"0E" plate mode event missed its scheduled start time
"0F" tip prime conflicts with tip prime rules
"10" number of read events defined invalid
"11" read event start time out of range
"12" number of samples out of range
"13" sampling interval out of range
"14"
number of plate mode kinetic reads out of range
"15" plate mode kinetic interval time too short
"16" read event missed its scheduled start time
"21" number of dispense events defined invalid
"22" tip prime volume out of range
"23" volume requested out of range
"24" dispense rate requested out of range
"25" dispense start time/kinetic interval out of range
"26" dispense kinetic interval out of range
"28" dispenser module not attached
"29" dispenser has not been initialized
"2A" dispenser has not been primed
"2B" invalid dispenser operation type requested
"2C" dispense event missed its scheduled start time
"30" number of shake events defined invalid
"31" shake start time out of range
"32" read event must follow shake event with repeat
"33" shake time out of range
multi filterset
BioTek Instruments, Inc.
