12. Remove the two
interchangeable. Each syringe should already be assembled in one piece, but if for
some reason there are two separate pieces, assemble them now: insert the white tip
of the syringe plunger into the barrel of the syringe and gently push it all the way
into the barrel.
13. Install both syringes:
•
Hold the syringe vertically with the threaded end at the top and the knurled
steel end at the bottom.
•
Screw the threaded end of the syringe into the bottom of the
Finger-tighten only.
•
Carefully pull down the knurled steel end of the syringe until it is resting
inside the hole in the
•
Pass a metal
of the syringe. Hold the syringe from rotating while tightening the
thumbscrew. Finger-tighten only.
The installed syringes should resemble the following:
Figure 13: The dispense module with the syringes installed
Synergy HT Operator's Manual
from their protective boxes. They are identical and
syringes
bracket .
thumbscrew up through this hole and thread it into the bottom
Syringes
Syringe
brackets
Thumbscrews
8: Install the Dispense Module |
syringe valve
