Perform these steps to remove both sets of internal dispense tubes and injector
heads:
1. Open the cable clamp to release the tubes.
2. Locate the tubing ports on the reader's rear wall. Turn each tube's
thumbscrew counterclockwise and gently pull the tube from the port.
3. Locate the injector heads. Turn each tube's thumbscrew counterclockwise to
disconnect the tube from the injector head.
Synergy HT Operator's Manual
Clean the Internal Components |
Cable
clamp
