Appendix D: Specifications
|

Technical Specifications

General Specifications

Microplates
All models accommodate standard 6-, 12-, 24-, 48-, 96- and 384-well
microplates with 128 x 86 mm geometry, and the Take3 and Take3 Trio Micro-
Volume Plate, and support:
Absorbance mode: plates up to 0.8" (20.30 mm) high
Fluorescence/Luminescence modes: plates up to 1.25" (31.75 mm) high
PCR tube trays up to 1.25" (31.75 mm) high (may require an adapter)
All models read 6-, 12-, 24-, 48-, 96- and 384-well microplates
Injector models dispense to 6-, 12-, 24-, 48-, and 96-well microplates
Hardware & Environmental
Light Source:
Dimensions:
Weight:
Environment:
Humidity:
Power Supply:
Power Consumption:
Incubation:
Plate Shaking:
Absorbance:
Xenon flash light source, 10W maximum average
power, lamp life 1 billion flashes (not user-
changeable)
Fluorescence:
Tungsten halogen, 20W power, lamp life 1000 hours
(user-changeable)
16" D x 15" W x 10" H (40.6 cm x 38 cm x 25.4 cm)
38 lb. (17 kg)
Operational temperature 18°C (64°F) to 40°C (104°F)
10% to 85% relative humidity (non-condensing)
24-volt 90W external power supply compatible with
100-240 V~; +10% @50-60 Hz
100 VA max, 130 VA max with injectors
Temperature control range from 4º over ambient
to 50ºC. Temperature variation ± 0.50°C across the
plate @ 37°C (250 µl per well with the plate sealed).
Low, Medium, High and Variable shaking speeds.
Shake time is programmable by the user.
