4.9.2

[96] Acknowledging an error

Type
b Input error reset +
I1
I2 b Input error reset -
- -
I3
I4 - -
Description:
Output 1 becomes TRUE if an acknowledgeable error message is present.
With each positive edge at input 1 or negative edge at input 2 an attempt is made to acknowl-
edge an present error message. If the message cannot be acknowledged (yet), there is no
reaction.
O1 I1 I2
1
0 1 x
0
1
x 1 0
0
I1
x x
Note:
If output 1 is connected with input 1, faults are acknowledged automatically.
08/10
08/10
Function Type
b
O1
O2 b
-
P1
P2 -
Function
Acknowl-edge fault.
None
Acknowl-edge fault.
None
Automatic Error Acknowledg-
ment
VPLC / PLC
VPLC / PLC
Function
"Message can be acknowl-
edged".
inverted output = O1
-
-
