404] Write Voltage Parameter (Peak); 405] Write Percentage Parameter; 406] Write Position Parameter - BONFIGLIOLI AGILE Applications Manual

5.7.1.4
Type
I1 % input value 1
b Delete buffer
I2
I3 b Write release
Wait until writing
I4 b
is finished
Description:
The peak value at the input is converted from percent to V and written as int parameter.
1 I [%] I [ 1 ] V
→
123.45% = 123.45 V
5.7.1.5
Type
% input value 1
I1
I2 b Delete buffer
b Write release
I3
Wait until writing
b
I4
is finished
Description:
The input value is not changed and written as int parameter. In this way, this function can also
be used for any other (int) parameter types.
5.7.1.6
Typ
e
Pos
I1
Input value
Pos
I2
b Write enable
I3
Wait until writing is
b
I4
finished
Description:
The input value is not changed and written as long parameter. In this way, this function can be
used for any long parameter types.
O1 = I2|I1 (High-word|Low-word)
114
114

[404] Write voltage parameter (peak)

Function
O1
O2
P1
P2

[405] Write percentage parameter

Function
O1
O2
P1
P2

[406] Write position parameter

Function
Low word
O1
High word
O2
P1
P2
Type Function
O 1 [%] → O [ 1 ] V
b
b inverted output = -1
i Parameter number
i Data set (0 ... 9) or index
Type Function
1 I [int]
b
b inverted output = -1
i Parameter number
i Data set (0 ... 9) or index
Typ Function
e
b O1 = I2|I1
b inverted output = -1
i Parameter number
i Data set (0 ... 9) or index
VPLC / PLC
VPLC / PLC
08/10
08/10
