Master Set sets all bits of the output value (Output = 0xFFFF).
Master Reset deletes all bits of the output value (Output = 0x0000).
Example
P1
1) 1: Bit 1
2) 4: Bit 4
3) 4: Bit 4
In example 2):

5.11.10 [221] Unite four bits to form a word

Type
I1 b input value 1
b input value 2
I2
b input value 3
I3
b input value 4
I4
Description:
The state of input 1 is copied to the bit of output O1 specified via P1, the state of input 2 to the
next bit, etc. All other bits of the output value are zero. If P1 > 12, bits will be lost.
Master Set sets all bits of the output value (Output = 0xFFFF).
Master Reset deletes all bits of the output value (Output = 0x0000).
Exam- P1
ple
1) 0
2) 5
3) 14
(P1>12)
Re example 2):
132
132
I1 O1 O2
0xF00F 1 0
0x00FF 1 0
0xFF00 0 1
Function Type
O1 %
%
O2
i
P1
-
P2
Copy
I1 to bit 0 of O1,
I2 to bit 1 of O1,
I3 to bit 2 of O1,
I4 to bit 3 of O1
I1 to bit 5 of O1,
I2 to bit 6 of O1,
I3 to bit 7 of O1,
I4 to bit 8 of O1
I1 to bit 14 of O1,
I2 to bit 15 of O1,
I3 not copied,
I4 not copied
VPLC / PLC
Function
I1, I1, I3, I4 united to form a
word
inverted output
Number of 1st bit (0 ... 15)
-
I4 I3 I2 I1
1 0 1 0
1 0 1 0
1 0 1 0
VPLC / PLC
O1 O2
0x000A 0xFFF5
0x0140 0xFEBF
0x4000 0xBFFF
