5.7.2.7
Type
- -
I1
- -
I2
I3 b Release read access
- -
I4
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a long value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
5.7.2.8
Type
- -
I1
I2 - -
b Release read access
I3
I4 - -
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a percent value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
5.8

Limiters

5.8.1

[440] Limiter (Const.)

Type
I1 % input value 1
I2 - -
- -
I3
b Master Reset
I4
Description:
The input value at I1 is limited to P1 (upper limit) and P2 (lower limit) and output.
1 P
O1 = 1 I
P 2
As long as status TRUE is present at I4 (Master Reset), the output value O1 is 0.
Note:
P2 can only be entered as a positive value.
118
118

[427] Read long parameter

Function
O1
O2
P1
P2

[428] Read word parameter

Function
Function
O1
O2
P1
P2
Type Function
%
Long value
%
i Parameter number
i Data set (0 ... 4)/index
Type Function
% Parameter value [%]
O1
O2 % inverted output = -1
i Parameter number
P1
P2 i Data set (0 ... 4)/index
Type Function
1 P
% O1 = 1 I
P 2
% inverted output = -1
% upper limit
% lower limit
VPLC / PLC
VPLC / PLC
Low word
High word
