2.2.8

Analog output block

Combining an analog function block output with a device function or an analog output (termin-
al):
− Drag a block "Analog Out" from the library to the function block output.
− Double-click the block "Analog Out". Select an output buffer.

Example:

Selected output
buffer
2
1
2.2.9 Example
Digital
Run Signal as Input Signal
Output O1 via output buffer (Bool1).

2.2.10 Syntax check

Start the syntax check by clicking button
message in bottom area. The cause of the error is marked in the editor window.

2.2.11 Translation and download (to frequency inverter)

Click button
them to the frequency inverter. Only if this function executed will the data in the frequency
inverter be changed. The syntax must be free from errors.
Before the translation and download, stop the PLC by clicking button

2.2.12 Starting the PLC

Run the function block opened in the editor by clicking on button

2.2.13 Stopping the PLC

Stop the started function block by clicking on button
14
14
Signal source for de-
vice function
2502
Signal source for analog
output (terminal)
61
to translate the function block program to parameter settings and download
VPLC / PLC
Example of device function
Reference frequency source1
AgilE:
2502 – PLC output frequency 2
Example of analog output (terminal)
Analog: Source MFO1A
AgilE:
61 – Abs. value PLC outp. percent 1
Analog
Analogue input MFI1A as input value
(Percentage 1).
Output O1 via buffer Percentage 1 (Per-
cent1).
. In the syntax check window, click on the error
.
VPLC / PLC
475 =
553 =
.
.
