7.3

Signals for digital outputs of device

The following output signals of the can be assigned to the digital outputs of the frequency in-
verter.
Operation mode
0 - Off
80 - PLC output buffer 1
81 - PLC output buffer 2
82 - PLC output buffer 3
83 - PLC output buffer 4
100 to 183
7.4

Signals for analog outputs of device

Via a multifunction output, the values of analog instructions can be output.
The following output signals of the function table can be assigned to the analog outputs.
Operation mode
Abs. value PLC
61 -
outp. percent 1
Abs. value PLC
62 -
outp. percent 2
PLC outp. per-
161 -
cent 1
PLC outp. per-
162 -
cent 2
146
146
Digital output is switched off
Digital output signal of an instruction. Signal source "2401 -
PLC output buffer 1" is the output signal. This signal source
contains the output value of the instruction assigned to signal
source 2401.
Digital output signal of an instruction. Signal source "2402 -
PLC output buffer 2" is the output signal. This signal source
contains the output value of the instruction assigned to signal
source 2402.
Digital output signal of an instruction. Signal source "2403 -
PLC output buffer 3" is the output signal. This signal source
contains the output value of the instruction assigned to signal
source 2403.
Digital output signal of an instruction. Signal source "2404 -
PLC output buffer 4" is the output signal. This signal source
contains the output value of the instruction assigned to signal
source 2404.
Operation modes inverted (LOW active).
Analog output signal of an instruction as an absolute value. Signal
source "2521 - PLC output percent 1" is the output signal. This sig-
nal source contains the output value of the instruction assigned to
signal source 2521.
Analog output signal of an instruction as an absolute value. Signal
source "2522 - PLC output percent 2" is the output signal. This sig-
nal source contains the output value of the instruction assigned to
signal source 2522.
Analog output signal of an instruction. Signal source "2521 - PLC
output percent 1" is the output signal. This signal source contains
the output value of the instruction assigned to signal source 2521.
Analog output signal of an instruction. Signal source "2522 - PLC
output percent 2" is the output signal. This signal source contains
the output value of the instruction assigned to signal source 2522.
