BONFIGLIOLI AGILE Applications Manual page 143

Table of functions
FT instruction
1343
FT input 1
1344
FT input 2
1345
FT input 3
1346
FT input 4
1347
FT-Target Output
1
1350
FT-Target Output
2
1351
1)
Inverted output of function 1 (in this example of OR function)
2)
Inverted output of function 2 (in this example of RX-Flip-Flop)
The outputs of the FT-instructions are available as sources and can be linked to the inputs of
other functions or output via digital outputs.
Example:
− Linking of AND function output with Start Clockwise Function, parameter
068 = "2402 - FT output buffer 2"
− Linking of RS-Flip-Flop output with digital output 1; Parameter
put 1
530 = "80 – FT-Output buffer 1"
08/10
08/10
Index 1 Index 2
2 - OR 10 - RS Flip-Flop
Superior
2004 - FT input 2101 - Outp.1
buffer 4 instruction 1
2003 - FT input 2009 - FT input
buffer 3 buffer 9
2002 - FT input 7 – FALSE
buffer 2
7 – FALSE 7 – FALSE
0 - Output not 2402 - FT-
usable globally Output buffer 2
0 - Output not 0 - Output not
usable globally usable globally
VPLC / PLC
VPLC / PLC
Index 3 Index 4
1 - AND 0 - Off (last table
item)
2006 - FT input 7 – FALSE
buffer 6
2005 - FT input 7 – FALSE
buffer 5
2201 - Outp.1 7 – FALSE
1)
instruction 1
2202 - Outp.1 7 – FALSE
2)
instruction 2
2401 - FT- 0 - Output not
Output buffer 1 usable globally
0 - Output not 0 - Output not
usable globally usable globally
Start clockwise
Operation mode digital out-
141
