423] Read Voltage Parameter (Eff.); 424] Read Voltage Parameter (Peak); 425] Read Percent Parameter; 426] Read Position Parameter - BONFIGLIOLI AGILE Applications Manual

5.7.2.3
Type
- -
I1
- -
I2
b Release read access
I3
I4 - -
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a voltage value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
5.7.2.4
Type
I1 - -
- -
I2
I3 b Release read access
- -
I4
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a voltage value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
5.7.2.5
Type
I1 - -
- -
I2
I3 b Release read access
- -
I4
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a percent value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
5.7.2.6
Type
- -
I1
- -
I2
I3 b Release read access
- -
I4
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a position value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
08/10
08/10

[423] Read voltage parameter (eff.)

Function

[424] Read voltage parameter (peak)

Function

[425] Read percent parameter

Function

[426] Read position parameter

Function
O1
O2
P1
P2
Type Function
% Parameter value [V]
O1
% inverted output = -1
O2
i Parameter number
P1
P2 i Data set (0 ... 4)/index
Type Function
O1 % Parameter value [V]
% inverted output = -1
O2
P1 i Parameter number
i Data set (0 ... 4)/index
P2
Type Function
O1 % Parameter value [%]
% inverted output = -1
O2
P1 i Parameter number
i Data set (0 ... 4)/index
P2
Type Function
%
Position
% value
i Parameter number
i Data set (0 ... 4)/index
VPLC / PLC
VPLC / PLC
Low word
High word
