Appendix C — Serial Configuration Commands
Communications
Host Port Parameters
Aux Port Parameters
Host Protocol
Preamble
Postamble
Response Timeout
Intercharacter Delay
LRC
Auxiliary/Configuration Port System Data
ACK/NAK Options
Polling Mode Options
Daisy Chain Autoconfigure
Daisy Chain Scanner ID
Read Cycle
Trigger Mode
Serial Trigger Character
External Trigger State
End of Read Cycle
Good Decode Reads
Multisymbol
Start Serial Trigger Character
End Serial Trigger Character
Scan Speed
Maximum Element
Gain/Tracking
AGC Settings
Focus
Tracking Adjustment
Symbologies
Narrow Margins/Symbology ID
Background Color
Code 39
Codabar
Interleaved 2 of 5
MS-890 Industrial Automation Scanner User Manual
<K100,baud,parity,stop bits,data bits>
<K101,aux port mode,baud,parity,stop bits,data bits,daisy
chain ID status,daisy chain ID>
<K140,protocol,address>
<K141,status,preamble character(s)>
<K142,status,postamble character(s)>
<K143,timeout setting>
<K144,time interval>
<K145,status>
<K146,aux port status,config port status>
<K147,RES,REQ,STX,ETX,ACK,NAK>
<K148,RES,REQ,STX,ETX,ACK,NAK>
<K150DAISY>
<K151,daisy chain scanner,daisy chain scanner ID>
<K200,trigger mode,trigger filter duration>
<K201,trigger character>
<K202,external trigger state>
<K220,end of read cycle mode,read cycle timeout>
<K221,number before output,mode>
<K222,number of symbols,multisymbol separator>
<K229,start trigger character>
<K230,end trigger character>
<K500,scan speed>
<K502,max element>
<K504,gain,tracking>
<K505,AGC sampling status,transition counter>
<K508,focus position,zero position>
<K520,tracking adjustment>
<K450,narrow margins status,symbology identifier status>
<K451,background color>
<K470,status,check character status,check character output status,
large intercharacter gap,fixed symbol length status,fixed symbol
length,full ASCII set>
<K471,status,start and stop match,start and stop output,large
intercharacter gap,fixed symbol length status,fixed symbol
length,check character type,check character output>
<K472,status,check digit status,check digit output,symbol length
#1,symbol length #2,guard bar status,range mode status>
