Installation Steps (cont.)
Installation Steps (cont.)
6. Attach the scanner to the wiring box with four attached mounting screws in the bottom
plate of the scanner, making sure that the gasket is evenly seated.
7. Mount the wiring box (see
14-4
Mounting screws
(4 corners of
base plate)
Wiring Box Ports
on page 14-5).
MS-890 Industrial Automation Scanner User Manual
