Calibration Routine

Calibration Routine
To calibrate gain, tracking, focus position, and scan speed automatically:
1. Click the Calibration button near the top of the screen.
2. Click the Calibrate button to start calibration.
A "Calibration in Progress..." message will be displayed on your monitor along with the
pass number and information on the focus position, gain, tracking and read rate.
Allow some time for the scanner to cycle through the settings. Do not move or disturb
the scanner or symbol while calibration is in progress. (It might take 2 to 3 minutes to
complete.)
3. When completed, the settings that provided the highest read rate will be selected. You
will see one of the following messages: "Calibration Passed" or "Calibration Failed".
If calibration passed, you will continue to see the read rate percentage and symbol
data in the open pane below the data.
Calibration by Serial Command
To start the calibration process by serial command, send
9-4
<@CAL>
MS-890 Industrial Automation Scanner User Manual
from ESP's Terminal.
