Navigating in ESP

To change scanner settings, or to access the Calibration , Raster/Laser , Terminal , Utilities ,
or Output Format views, click the App Mode button.
To return to EZ Mode, click the EZ Mode button.
To make changes to configuration settings in the tree controls:
1. Left-click on the + to expand
menu items.
2. Double-click the desired
parameter and single-click
in the selection box to view
options.
3. Place your cursor in the
selection box, scroll down
to the setting you want to
change, and single-click
the setting.
MS-890 Industrial Automation Scanner User Manual
4. Left-click again on the open screen to complete the
selection.
5. Right-click on the open screen and select Save to
Reader to implement the command in the scanner.
You can send the command without saving it, or you
can send and save the command simultaneously.
Using ESP
X
The denotes the
default option setting.
2-15
