Contents
Step 1 Check Required Hardware................................................................................................ 1-2
Step 2 Connect the System.......................................................................................................... 1-3
Step 3 Position Scanner and Symbol ........................................................................................... 1-5
Step 4 Install ESP......................................................................................................................... 1-6
Step 5 Select Model ..................................................................................................................... 1-7
Step 6 Autoconnect ...................................................................................................................... 1-8
Step 7 Receive Settings ............................................................................................................... 1-9
Step 8 Calibrate.......................................................................................................................... 1-10
Step 9 Test Read Rate ............................................................................................................... 1-11
Step 10 Configure the Scanner in ESP ...................................................................................... 1-12
Step 11 Save Configuration in ESP............................................................................................ 1-13
This chapter is designed to get your MS-890 up and running quickly, using the EZ Button
or ESP (Easy Setup Program). Following these steps will allow you to get a sense of the
scanner's capabilities and to test symbol decode performance.
Detailed setup information for installing the scanner into your application can be found in
the subsequent chapters.
Important: If you are switching from an MS-880 to an MS-890 in your application, follow
these steps when you open ESP:
1. With your MS-890 connected to the host computer, open your most recent MS-880 .esp file.
2. Connect to the MS-890 and send all settings.
3. Click the Switch Model button at the top of the ESP view. When you see the model
menu, select the MS-890.
4. Receive settings.
Note: After receiving settings, you can delete the previous MS-880 model by opening
the Model dropdown menu from the menu toolbar, selecting Remove Model, and
selecting MS-880.
MS-890 Industrial Automation Scanner User Manual
1 Quick Start
1-1
