Optoelectric Control
Control Trigger 1 Status
When Control Trigger mode is enabled, Control Trigger #1 takes over
Definition:
Input 1 (see
configuration from the configuration database. Active state is set by Input 1
serial command.
Serial Cmd: <K226,mode,# active database settings,latch on trigger,timer/switch
value,control trigger 1
database cycles>
Disabled
Default:
Options: 0 = Disabled
1 = Enabled
Control Trigger 2 Status
Definition: New Master Pin is used for Control Trigger #2. When enabled and Mode
is set to Control Trigger, this input is used to select an optoelectric configuration
from Configuration Database. Active State is "Active Closed".
Serial Cmd: <K226,mode,# active database settings,latch on trigger,timer/switch
value,control trigger 1
database cycles>
Default: Disabled
Options: 0 = Disabled
1 = Enabled
Control Trigger 3 Status
Trigger Input is used for Control Trigger #3. When enabled and Mode is
Definition:
set to Control Trigger , this input is used to select an optoelectric configuration
from the Configuration Database. Active State is set by the External
Trigger State serial command.
Serial Cmd: <K226,mode,# active database settings,latch on trigger,timer/switch
value,control trigger 1 status,control trigger 2
database cycles>
Default: Disabled
0 = Disabled
Options:
1 = Enabled
9-12
Input Mode on page 6-19) and uses it to select an optoelectric
status,control trigger 2 status,control trigger 3 status,
status,control trigger 2
MS-890 Industrial Automation Scanner User Manual
status,control trigger 3 status,
status,control trigger 3 status,
