Daisy Chain Autoconfigure

Note: This command is not available in ESP.
Usage:
For quick setup and configuration of the daisy chain network.
Definition:
Daisy Chain Autoconfigure is issued to the master scanner in the daisy
chain and the software responds as follows:
• Counts the number of secondary scanners in the daisy chain.
• Assigns an internal ID number (1...n) to each secondary scanner, where
the first secondary scanner is number 1 (and its own ID being a 0).
• Propagates the communications settings and the relevant operating
modes of the master scanner to the host and auxiliary ports of each
secondary scanner.
• Resets each secondary scanner.
• Verifies that each secondary scanner has acquired the new settings.
Serial Cmd: <K150DAISY>
When setting up a daisy chain operation, follow these steps:
1. Set the master (the scanner connected to the host) scanner to Serial.
This sets all the scanners in the daisy chain to Serial when the command is carried out.
Before Autoconfigure you must set the primary scanner to Serial (S):
Host
2. Send <K150DAISY>
3. If necessary, set the master scanner to Edge.
After Autoconfigure you may set the primary scanner to Edge (S), but the other
scanners must remain in Serial (S):
Host
MS-890 Industrial Automation Scanner User Manual
Primary
Scanner
S
command.
Primary
Scanner
E
Secondary
Scanner
S
Secondary
Scanner
S
Communications
Secondary
Scanner
S
Secondary
Scanner
S
3-19
