Contents
Wiring Box Description ............................................................................................................... 14-2
Installation Steps ........................................................................................................................ 14-3
Wiring Box Ports......................................................................................................................... 14-5
Wiring Box PCB with Connectors ............................................................................................... 14-8
Mounting Plate............................................................................................................................ 14-9
This section has instructions for assembling, wiring and using the MS-890's optional
Wiring Box. When this option is selected, the MS-890 and wiring box option are shipped
as an assembly.
MS-890 Industrial Automation Scanner User Manual
14 Wiring Box
14-1
