Explanation of Modifiers for Code 39, Codabar, and Interleaved 2/5
• For Code 39, Codabar and I–2/5, the modifier indicates Check Character and Check
Character Output Status.
• For Code 39 only, Full ASCII needs to be enabled to see modifiers 4, 5, and 7.
Modifier Check Character
0
1
3
4
5
7
Example:]A5 indicates a Code 39 symbol with Check Character and Check Character
Output Status enabled and Full ASCII conversion performed.
Explanation of Modifiers for Other Symbologies
• For Code 128, a 1 indicates EAN-128; otherwise the modifier is a 0.
• For all other codes, the modifier is 0.
MS-890 Industrial Automation Scanner User Manual
Check Character
Output
Disabled
Enabled Enabled
Enabled Disabled
Disabled
Enabled Enabled
Enabled Disabled
Full ASCII conversion performed
N/A
N/A
Symbologies
(Code 39 only)
No
No
No
Yes
Yes
Yes
5-25
