View

View
The View menu allows you to move quickly between interfaces
without using the icon buttons on the App Mode toolbar. It also
allows you to access the Bar Code Dialog.
Bar Code Dialog
In the Bar Code Dialog you can create symbols by typing the text
you wish to encode. This is a useful tool for creating configuration
symbols, allowing you to configure your scanner by reading the
symbols you create.
Choose a spatial
orientation for the
new symbol.
The symbols you create
will be displayed in the
field at the bottom of the
Bar Code Dialog.
See Bar Code Configuration
MS-890 by decoding symbols.
2-14
on page A-23 for more information about configuring the
MS-890 Industrial Automation Scanner User Manual
Drag configuration commands
from the tree controls directly
into this field to encode new
symbols.
Create a caption
for the symbol
that matches the
encoded data, or
write your own
caption.
Click the Differences from Default
Settings button to create a symbol
encoded with configuration settings
that differ from ESP defaults.
Differences from Default
viewed on the Differences tab in the
Utilities view.
Click Add start configuration code
and Add end configuration code;
Save Settings to add a symbol that
will enable Bar Code Configuration
mode and a symbol that will save all
new configuration settings. (Both
symbols shown at left).
can be
